RedSabre / CW 1500W D16T5 F60 Collimating Lens for SUP23T
Catalog SKU LWD-OPT-004
Sold out
Compare the original part number, head version and dimensions before ordering. Choose a machine to see its model-specific requirements.
Selected configuration:
Read specifications and fitment ↓Change machine ↗Machine fitment
Find your exact model below, then check the required head, connection or original part number.
| Machine | Required configuration |
|---|---|
| Everlast RedSabre 1500X | Requires SUP23T on the installed gun; match the original optical or wire-feed specification. Confirm the gun label; the 1500X model name does not establish its head revision. |
| Everlast RedSabre 2000X | Requires SUP23T on the installed gun; match the original optical or wire-feed specification. Confirm the gun label: published 2000X information names different head revisions. |
| Lasers Only CW 1500W 4-in-1 | Requires the SUP23T welding head. Match the complete lens or cartridge specification; machine wattage alone is insufficient. |
An aftermarket replacement optic for the specified SUP welding-head configuration.
Specifications
| Part number | LWD-OPT-004 |
|---|---|
| Diameter | 16 mm |
| Thickness | 5 mm |
| Focal length | 60 mm |
| Pack contents | 1 bare lens |
Part-specific requirements
Head compatibility to confirm: SUP23T heads. For a RedSabre or Lasers Only machine, first verify that the installed head is one of these models and that the complete optical or cartridge specification matches the original.
Fitment limits: No SUP33T compatibility is claimed. An aftermarket sourcing candidate is not an OEM-certified machine replacement. Do not substitute this F60 collimator for an air-cooled Everlast F50 optic.
Reference image may show several configurations. This listing includes only the single part and specification named above.
